SUMMIT Shallow Depth Panel Ready Built-in All-refrigerator with Adjustable shelves

Summit's shallow depth series of built-in undercounter refrigeration offers ENERGY STAR-certified choices for improved efficiency and modern style. The FF195IF, sized at just 19 inches wide and 18 inches deep, features a jet-black cabinet with a sealed back for easy cleaning. Its height is adjustable between 33 7/8 and 34 1/2 inches, providing flexibility to suit various spaces. The stainless steel door comes with an integrated stainless steel frame designed to accept panels, allowing customization or blending into cabinetry design. Customers can provide their own handles to match their settings. The space-saving right-angle plug and integrated hinge offer added flexibility in unit placement.

Highlights

• 18" Shallow Depth: Ideal for home wet bars, island kitchens, and other applications with limited footprint space.

• ENERGY STAR Certified: Rated by the DOE for improved efficiency, saving energy and reducing utility costs.

• Panel-Ready Door: Accepts full overlay panels for customization; panel size: 18 7/8" W x 31 9/16" H and at least 3/4" thick; customers provide handles.

• Built-in Capable: Front-breathing design allows installation under the counter.

• Automatic Defrost: Reduced maintenance with auto defrost system.

• Adjustable Shelves: Three glass shelves with a brake system ensure safe, optimal storage.

• Door Racks: Two chrome racks accommodate a variety of sizes for optimal interior storage.

• LED Lighting: Automatically illuminates when the door is open for an attractive and energy-efficient view.

• Black Interior Finish: Allows for easy cleaning and organization within the unit.

• Adjustable Thermostat: Dial thermostat with seven temperature settings offers easy temperature management.

• Versatile Construction: Meets both residential and commercial standards.

• Sealed Back: Space-saving design for easier cleanability.

• Right-Angle Plug: Provides flexibility in unit placement without needing added depth.

• Factory Installed Lock: Door includes lock and key for optional security.

• Height Adjustable: Four leveling legs allow height adjustment between 33 7/8" and 34 1/2".

• Fully Finished Black Cabinet: Allows freestanding use.

• 100% CFC Free: Environmentally friendly design without ozone-damaging chemicals.

• CARB Compliant: Uses environmentally friendly hydrocarbon-based refrigerant meeting current CARB regulations.

• Ideal for home wet bars, island kitchens, and other applications with limited footprint space
• Rated by the DOE to perform with more efficiency than federal standards require, saving your unit energy and you on higher utility costs
• ETL-S listed to NSF-7 standard and meets UL-471 for use in commercial settings
• Integrated stainless steel door frame accepts full overlay panels, allowing you to customize the refrigerator door or blend it into your cabinetry design; panel size: 18 7/8" W x 31 9/16" H and at least 3/4" thick; 10 lbs. maximum; customers provide their own handles
• Front-breathing design lets you make the best use of space by installing your appliance under the counter
• Reduced user maintenance with auto defrost system
• Three glass shelves with brake system ensures safe, optimal storage
• Two chrome racks accommodate a variety of sizes for optimal interior storage
• Automatically illuminates when the door is open for an attractive and energy efficient view
• Allows for easy cleaning and organization within the interior of the unit
• Dial thermostat with seven temperature settings offers easy temperature management
• Meets both residential and commercial standards
• Space saving design for easier cleanability
• Provides flexibility in unit placement without needing added depth
• Door includes a lock and key for optional security. If planning to use the lock, be sure to include a 5/8" hole in the lower center of your custom panel
• Four leveling legs allow you to adjust the height between 33 7/8" and 34 1/2" to best fit your undercounter space
• Allows the unit to be used freestanding
• Environmentally friendly design does not contain ozone-damaging chemicals
• Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Summit's shallow depth series of built-in undercounter refrigeration includes ENERGY STAR certified choices for improved efficiency in modern style. The FF195IF features a versatile design that meets NSF-7 and UL-471 commercial standards but is also approved for residential use. Sized at just 19 inches wide and 18 inches deep, it comes in a jet black cabinet with a sealed back for easy cleaning of the unit. The height can be adjusted between 33 7/8 and 34 1/2 inches to best suit your space. The stainless steel door features an integrated stainless steel frame designed to accept panels, allowing you to create a custom look under the counter (panel size: 31 9/16 inch H x 18 7/8 inch W at 3/4 inch thick). Customers provide their own handle to best match their setting. The space-saving right-angle plug and integrated hinge provide added flexibility in unit placement. Inside, the FF195IF utilizes an internal fan to ensure the unit is evenly cooled from top to bottom. An automatic defrost system ensures minimal user maintenance, while LED lighting allows full visibility of stored items in the jet black interior. Three adjustable slide-out glass shelves provide flexible storage capacity inside the 3.1 cu. ft. interior. A shelving brake system offers added safety when moving and storing contents, while two chrome door racks are ideal for storing condiments, canned beverages, and other larger items. The dial thermostat, with seven temperature settings, is located in the front upper-right corner for easy temperature management. The FF195IF is ENERGY STAR certified and designed for built-in or freestanding use. For a similar glass door unit commercially approved for outdoor use, see the SPR489OSPNR.

Overview
Height of Cabinet	33.88" (86 cm)
Width	19.0" (48 cm)
Depth	18.0" (46 cm)
Depth with door at 90°	35.0" (89 cm)
Capacity	3.13 cu.ft. (89 L)
Defrost Type	Automatic
Door	Panel-Ready
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Energy Usage/Year	259.0kWh/year
Amps	1.3
Voltage/Frequency	115 V AC/60 Hz
Weight	70.0 lbs. (32 kg)
Shipping Weight	75.0 lbs. (34 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101074931
Refrigerator Features
Door Swing	RHD
Reversible	Factory Reversible
Height Adjustable	Yes
Shelf Type	Glass
Shelf Qty	3
Adjustable Shelves	Yes
Thermostat Type	Dial
Fan Type	Interior
Refrigerant Type	R600a
Refrigerant Amount	0.88oz.
High Side PSI	320.0
Low Side PSI	120.0
Level Legs Qty	2
Interior Light	Yes
Temperature Range	34 to 50 F
Sound Level	33.4 dB
Dimensions
Interior Height	29.0" (74 cm)
Interior Width	16.0" (41 cm)
Interior Depth	12.75" (32 cm)
Compressor Step Height	7.0" (18 cm)
Compressor Step Width	16.0" (41 cm)
Compressor Step Depth	6.25" (16 cm)
