The SUMMIT SWC1966 is a full-sized dual-zone wine cellar designed for optimum wine storage with user-friendly convenience. Measuring just under 24 inches wide and 27 inches deep, this unit can store up to 160 standard 750ml Bordeaux bottles on slide-out wooden shelves. Alternatively, it can hold up to 118 larger Burgundy-style bottles or 22 champagne bottles and 132 Bordeaux-style bottles. The SWC1966 features two digital thermostats that allow you to easily manage the temperature zones, with an LED display showing temperatures in either Celsius or Fahrenheit. The larger lower compartment is ideal for red wines, which are best stored between 55º and 72ºF, while the upper zone is designed for white wine and champagne, stored between 41º and 55ºF. Recessed LED lighting adds an attractive touch. Additional features include a Sabbath mode setting, open door alarm, temperature memory function, and high-temperature alarm for added protection. The unit has a jet-black cabinet and a reversible stainless steel trimmed glass door for a full interior display, complemented by a sleek stainless steel handle and a factory-installed lock for added security. This wine cellar can be used freestanding or built-in with extra rear clearance.
Highlights
-
Large Capacity: The interior can hold up to 160 standard 750ml Bordeaux-style bottles. It can also accommodate 118 wider Burgundy-style bottles or 22 champagne bottles and 132 Bordeaux-style bottles.
-
Double-Pane Tempered Glass Door: The slightly tinted glass door provides a full interior view and features a stainless steel trim for added accent.
-
Two Temperature Zones: The lower zone is ideal for storing red wine with a temperature range of 55ºF to 72ºF, while the upper zone is perfect for white and sparkling wine stored between 41ºF and 55ºF.
-
Commercial Design: Meets UL-471 commercial standards.
-
Digital Thermostats: Easy-to-use digital controls allow you to set and adjust the two temperature zones separately, with an LED display in Celsius or Fahrenheit.
-
LED Lighting: Recessed lighting offers an elegant and efficient view of your wine collection.
-
Slide-Out Wooden Shelves: Fourteen wooden shelves provide proper storage for your bottles.
-
Factory Installed Lock: A keyed lock ensures trusted security.
-
Reversible Door: The user-reversible door swing provides flexibility in placement.
-
Fully Finished Black Cabinet: Allows the unit to be used freestanding.
-
Professional Handle: A stainless steel handle completes the professional look.
-
Automatic Defrost: The auto defrost operation reduces user maintenance.
-
Modified Built-In Use: The unit can be installed in built-in applications with at least 2 inches of rear clearance for adequate ventilation.
-
High-Temperature Alarm: An audible alarm sounds if the storage temperature rises out of the recommended range.
-
Open Door Alarm: An alarm sounds if the door is left open for more than 60 seconds.
-
Temperature Memory Function: The unit retains its last settings when power is restored after a power loss.
-
Sabbath Mode: An optional setting allows you to disable the lighting and alarm for up to 48 hours.
-
Stainless Steel Kickplate: Provides a sleek look with added protection.
-
100% CFC Free: Environmentally safe operation with no ozone-damaging chemicals.
-
CARB Compliant: Uses an environmentally friendly hydrocarbon-based refrigerant that meets current CARB regulations for a greener footprint.
- Interior can hold up to 160 standard 750ml Bordeaux style bottles. If using this wine cellar for wider Burgundy style bottles, you can hold up to 118. For champagne, the interior can hold 22 bottles (plus an additional 132 of the standard Bordeaux style)
- Slightly tinted glass provides full view of interior, with a stainless steel trim for added accent
- Lower zone is ideal for storing red wine (temperature range: 55 F to 72 F) while the upper zone accommodates white and sparkling wine stored between 41 F and 55 F
- Meets UL-471 commercial standards
- Set and adjust two temperature zones separately with easy-to-use digital controls with an LED display in Celsius or Fahrenheit
- Recessed lighting offers an elegant, efficient view of your collection
- 14 wooden shelves offer proper storage
- Keyed lock for trusted security
- User-reversible door swing allows for more flexibility in placing the unit
- Allows the unit to be used freestanding
- Stainless steel handle completes the professional look
- Reduced user maintenance with auto defrost operation
- Unit can be installed in built-in applications with at least 2" of clearance in the rear to ensure adequate ventilation
- Audible alarm sounds if the storage temperature rises out of recommended range
- Alarm sounds if the door is left open for more than 60 seconds
- Unit will retain its last settings when power is restored in the event of power loss
- Optional setting lets you disable the lighting and alarm for up to 48 hours
- Sleek look with added protection
- Environmentally safe operation with no ozone-damaging chemicals
- Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SUMMIT SWC1966 is a full-sized dual zone wine cellar designed for optimum wine storage with user-friendly convenience. Sized at just under 24" wide and 27" deep, the SWC1966 can store up to 160 standard 750ml Bordeaux bottles on slide-out wooden shelves. Alternatively, this unit can hold up to 118 larger Burgundy style bottles (often used for Chardonnay or Pinot Noir) or a combination of 22 champagne bottles and 132 Bordeaux style. Two digital thermostats let you manage the temperature zones with ease and include an LED temperature display that can be shown in Celsius or Fahrenheit. The larger lower compartment is best suited for red wines stored between 55 and 72 F, while the upper zone is designed for white wine and champange stored between 41 and 55 F. Recessed LED lighting offers an attractive touch. Additional features include a Sabbath mode setting, open door alarm, temperature memory function in case of power loss, and high temperature alarm for added protection. The SWC1966 has a jet black cabinet and reversible stainless steel trimmed glass door that offers a full display of the interior. A sleek stainless steel handle completes the look, and a factory installed lock offers added security. This unit can be used freestanding or built-in with extra rear clearance. See the user manual for more information. With its ideal size and handy features, the SWC1966 is an elegant yet affordable wine cellar for full storage needs.
Height of Cabinet |
69.75" (177 cm) |
Width |
23.63" (60 cm) |
Depth |
26.63" (68 cm) |
Depth with Handle |
27.75" (70 cm) |
Depth with door at 90° |
48.75" (124 cm) |
Capacity |
15.9 cu.ft. (450 L) |
Bottles |
160 bottles |
Defrost Type |
Automatic |
Door |
Glass |
Cabinet |
Black |
US Electrical Safety |
ETL |
Canadian Electrical Safety |
ETL-C |
Amps |
1.7 |
Voltage/Frequency |
115 V AC/60 Hz |
Weight |
187.0 lbs. (85 kg) |
Shipping Weight |
261.0 lbs. (118 kg) |
Parts & Labor Warranty |
1 Year |
Compressor Warranty |
5 Years |
UPC |
761101031972 |
Number of Zones |
2 |
Door Swing |
RHD |
Reversible |
Yes |
Shelf Type |
Wood |
Shelf Qty |
14 |
Thermostat Type |
Digital |
Interior Light |
Yes |
Fan Type |
Interior and Exterior |
Refrigerant Type |
R600a |
Refrigerant Amount |
1.91 oz. |
High Side PSI |
270.0 |
Low Side PSI |
105.0 |
Interior Height 1 |
29.5" (75 cm) |
Interior Width 1 |
19.75" (50 cm) |
Interior Depth 1 |
21.0" (53 cm) |
Compressor Step Height |
3.75" (10 cm) |
Compressor Step Width |
19.75" (50 cm) |
Compressor Step Depth |
5.5" (14 cm) |
Temperature Range |
41°F to 55°F (upper zone); 55°F to 72°F (lower zone) |
Interior Height 2 |
31.0" (79 cm) |
Interior Width 2 |
19.75" (50 cm) |
Interior Depth 2 |
21.0" (53 cm) |
Sabbath Mode |
Yes |
Sound Level |
33.7 dB |
