Type of beverage Ristretto / 2 x Ristretto.
Espresso / 2 x Espresso. Espresso Macchiato / 2 x Espresso Macchiato. Coffee / 2 x Coffee. Americano / 2 x Americano. Caffe Latte / 2 x Caffe Latte. Latte Macchiato / 2 x Latte Macchiato. Cappuccino / 2 x Cappuccino. Flat White / 2 x Flat White. Milk froth / 2 x Milk froth. Warm milk / 2 x Warm milk. Hot water / 2 x Hot water.
Operation One touch control panel and an interactive visual display.
Rotary knob and TFT touch display operation.
Clear text display in 44 languages.
Personalization function, up to 8 beverages can be personalized and memorized.
4 beverage size settings from small to extra large; can be individually adjusted to match the size of the cup.
8 coffee strength levels from very mild to extra strong.
Coffee: 3 grades.
Hot water: 8 grades.
4 coffee-milk ratio levels.
Adjustable grinding level.
Height-adjustable coffee dispenser 2 3/4" - 5 7/8".
Easy access to water tank, milk and coffee bean container behind the door.
Features Non-wearing grinding unit with ceramic discs.
Separate drawer for second ground coffee type.
Water pump with 275 psi ( 19 bar) pressure.
Double grinding and brewing cycles for two beverages.
For double beverage order, two grinding and brewing cycles.
Beverage dispenser with integrated milk system.
Insulated stainless steel milk container for up to 17 oz. ( 0.5 litres).
Integrated LED lighting.
Removable bean container with aroma protecting lid for 1.1 lbs., allows for an effortless exchange of different types of coffee beans.
Automatic adjustment of ground coffee quantity.
Removable 2.5 quarts (2.4 liter) ( 2.4 litre) water tank.
Electronic water filter exchange indicator.
Electronic fill level control for drip tray and container for coffee residue.
Home network integration for digital services (Home Connect) either via cable connection LAN (recommended) or wireless via WiFi.
The use of the Home Connect functionality depends on the Home Connect services, which are not available in every country. For further information please check: home-connect.com.
Safety Child lock.
Cleaning Fully automatic rinse program when machine is turned on/off.
Automatic steam cleaning of the milk system after every beverage.
Automatic cleaning and descaling program.
Emptying program to prepare the appliance for holiday or transportation.
Empty-grinding function to remove coffee residues from the system when switching bean types.
Removable brewing unit.
Coffee residue container and drip tray dishwasher-safe.
Beverage dispenser dishwasher-safe.
Planning notes Door hinge not reversible.
Ideal installation height 3.1 ft - 4.8 ft. (top edge of bottom niche).
The front of the appliance extends 1 7/8" from the furniture cavity.
When installing in a corner a side clearance is required.
Door opening angle appr. 110(degree) (delivery status) - mounting distance to the wall has to be at least 13 3/4".
Door opening angle appr. 155(degree) - mounting distance to the wall has to be at least 25 9/16".
Door opening angle appr. 92(degree) - mounting distance to the wall has to be at least 3 15/16" (spare part No. 00636455).
Installation directly above WS461 (5 3/8" tall) high warming drawer in 23 1/4" standard cut-out niche.
The LAN port can be found at the back on the lower right side.
Special accessories (order as spare parts):
Part No. 17000705 Water filter Part No. 00311819 Descaling tablets Part No. 00311769 Cleaning tablets Part No. 00636455 Door hinge restrictor (92(degree) opening angle) Part No. 11015223 Bean container with lid
Rating Total rating 1.6 KW.
Connection cable 39" with plug.
Plan for an ethernet / LAN cable or connect via WiFi.
